Google Nest Power Connector

Your Price $24.99

Google Nest thermostats are designed to work without a C wire in most homes, but for some systems, including heating-only, cooling-only, zone-controlled, and heat pump systems, you’ll need a Nest Power Connector or C wire. The Nest Power Connector is a simple, affordable alternative to a C wire if your heating and cooling system requires one to power your Nest Thermostat.

  • Costs less than hiring an electrician to install a new C wire through your walls
  • Installation is simple
    • It attaches to your furnace, air handler, or zone controller
    • It comes with simple instructions; no wiring or drilling required
  • The Nest Power Connector is only compatible with 24 VAC systems; it won’t work with millivolt or high voltage systems
  • The Nest Power Connector is the Nest thermostat C wire adaptor that’s designed specifically for Nest thermostats
Availability: In stock
SKU
5000.991

Details

Get Pro installation at checkout or install it yourself.

The Nest Power Connector doesn’t require any new wiring or drilling. It attaches to your furnace, air handler, or zone controller and comes with simple instructions for easy installation. And if you don’t want to install it yourself, you can always hire a pro. See how it’s installed.


Tech Specs

Dimensions Wiring Length Weight Operating Temperature Certification Color Materials

Height: 2.89 in (73.44 mm)

Width: 2.1 in (53.70 mm)

Depth: 0.57 in (14.50 mm)

7.48 in (190 mm)

2.17 oz (61.5 g)

–22° to 140℉ (–30° to 60℃)

–22° to 140℉ (–30° to 60℃)

Snow

Made with 46% post-consumer recycled materials (by weight).



What you can expect in the box

  1. Nest Power Connector
  2. Wire connectors
  3. Wire labels
  4. Sticky pad
  5. Installation guide
  6. Safety, warranty, and regulatory guide

Requirements

Requires a compatible Nest thermostat and HVAC system.

Find out if your home requires the Nest Power Connector to be compatible with Nest thermostats at g.co/nest/works.

Works with the Nest Thermostat, Nest Thermostat E, and 3rd gen Nest Learning Thermostat. Identify your thermostat at nest.com/whichthermostat.

Works with 24 VAC systems only. Millivolt and high-voltage systems are incompatible.

For the Nest Learning Thermostat, 1st gen and 2nd gen, consult with a Nest Pro.
